ET03

CoCr Dental Alloy for Framework and Partial Beryllium-free

ET03 CoCr Dental Alloy for Framework and Partial Beryllium-free

Description:
Available forms: columnar ingot
Compositions:

Co:62%
Cr: 27%
Mo:6%
Fe:2.5%
Si:1.3%
and the rest

Melting range: 1350°C~1370°c

Yield strength: 520MPa
Elongation:2%
Elastic Modulus: 210Gpa

Vickers hardness: 360HV₁₀

Size:Diameter 8mm, height 17mm

SDT-ET03 Co-Base Dental Alloy

CoCr Dental Alloy for Framework and Partial Beryllium-free

DSEX PRO H

Dental 3D Scanner

Ultra-high Accuracy
Unparalleled Details
Outstanding Scan Speed
Flexible Workflow
Backstage Data Processing
Versatile Scan Modes

DSEX PRO H Dental 3D Scanner

DSEX PRO H Dental 3D Scanner , developed and manufactured by SHINING 3D, is a 3D dental scanner with powerful functions for multiple applications covering scans of impressions, plaster models, articulators, implant abutments, etc. Its high-resolution cameras, advanced algorithms, and user-friendly interface bring you with superior data quality with optimal experience.

Ultra-high Accuracy Scan accuracy ≤ 8 μm assures reliable scan result, satisfying the requirement of various applications in dental industry completely.
	Unparalleled Details Equipped with dual 5.0 MP high resolution cameras, AutoScan-DS-EX Pro(H) can capture every detail of the components meticulously.

	Flexible Workflow Set up your own workflow as you prefer, increasing work efficiency like never before, all-in-one and triple tray are available to get complete scan data with less steps.
Backstage Data Processing Scan and backstage data processing can be carried out simultaneously, making the whole process more efficient.
	Versatile Scan Modes The new software associated with AutoScan-DS-EX Pro(H) can support versatile scan modes, including Multi Path Scan, High Quality Scan, AI Scan, Texture Scan, HDR Mode Scan, Reduce High Brightness Scan, etc.

VERSATILE APPLICATION

AutoScan-DS-EX Pro(H) supports multiple dental scan applications.

TECHNICAL SPECIFICATIONS

Camera Resolution         2*5.0 MP
Accuracy                     8 μm
Scan Time                     Bite scan: 6.5s; Upper/Lower jaw scan: 14s;1~4 dies scan: 21.5s; 5~8 dies scan: 25.5s; Impression scan: 31s;
Articulator Scan              Support articulator transfer
Output Format                STL, PLY, OBJ
Light Source       Blue Light
Dimension                      420*260*270 mm
Weight                           5.0 Kg
Interface                         USB 3.0
Power Supply                  DC 24V

* Based on Shining 3D internal test standard.

DSEX PRO C

Dental AutoScan

8s for bite scan

DSEX PRO Dental AutoScan

EVEN FASTER SCAN SPEED
With increased scan speed, a single jaw scan can be finished in 12 seconds. The entire process of a separate-die order can be completed within 2 minutes and a non-separated-die order within 2.5 minutes.
INTELLIGENT ADD-SCAN
When it comes to gaps, the AutoScan-DS-EX Pro can compute an optimized scan path and rescan to fill the unscanned holes automatically. Users don’t have to rescan manually.
OPTIMIZED NON-SEPARATED MODEL SCAN
Intelligent path planning for non-separated model scan ensures optimum scan results and higher efficiency.
FULL RANGE OF ARTICULATORS
The AutoScan-DS-EX Pro supports scanning multiple types of articulators on the market.
STATIC & DYNAMIC ARTICULATOR SCAN
Apart from the existing static scanning mode, a new dynamic scanning mode is now available to capture the full relationship of both jaws and further improve precision of occlusion.

This added feature is easy to operate and will result in greater efficiency.

TECHNICAL SPECIFICATIONS

Camera resolution :1.3 MP

Accuracy < 10μm
Scan time :8s for bite scan; 12s for upper / lower jaw scan; 13s for 1-4 dies scan; 21s for 5-8 dies scan; 58s for impression scan
Output format :STL / OBJ / PLY
Light source :Blue light
Dimensions: 385x250x270 mm
Weight :5kg
Interface:USB 3.0
Power supply:DC 24 V

Computer configuration requirements:
--System: win7, win10 (64-bit only)
--Port:The scanner needs a USB 3.0 port; the scanner dongle needs a USB port, regardless of porttype
--Graphics card: discrete graphics card, NVIDIA GTX640 or GTX750 and above
--CPU: Intel R CoreTM i5 ( i5 or higher)
--Memory: 8G and above
--Turn off the firewall

DSEX PRO C

DSEX PRO Dental AutoScan
